Vision X - Marine Grade Xmitter Prime Xtreme LED Light Bar

  • Sale
  • Regular price $299.00


Harnessing Unbeatable Power
Whether you choose the 4″ bar or the 50″ bar, you can rest assured that the LEDs inside of the Xmitter Prime Xtreme are the best 5-Watt LEDs obtainable. Top-binned and perfectly constructed, these high powered LEDs are capable of outputting 528 raw lumens each.

The Brightest LED Light Bar On The Market
Since the Xmitter Prime Xtreme Single Stack was first launched, it has held the title of “Most Raw Lumens Per Inch”. Pumping out nearly 1,000 raw lumens per inch, the Xmitter Prime Xtreme is unmatched in terms of effective power and performance.

Prime Drive Technology
Prime Drive Technology from Vision X Lighting controls vital functions such as temperature control and dimming on your LED Light Bar. This advanced technology can increase or decrease the intervals at which the LEDs turn on and off in order to lower the bars overall temperature and maximize the lifespan.

Saltwater Protection
The unique gloss coating used on Maritime products from Vision X greatly reduces the dramatic impact that saltwater has on traditional lighting fixture housings.



Marine Grade Black also Available.



Features

Type : 5-watt

  • High Powered 5 Watt LEDs
  • Up to 47,520 Raw Lumens
  • Marine Grade Coating



SPECIFICATIONS

ITEM # PART # BEAM LENGTH # OF LEDs RAW LUMENS EFFECTIVE LUMENS WEIGHT INPUT VOLTS WATTS AMP DRAW
XIL-PX12MW Mix 7.90″ 12 6,336 lm 4,440 lm 5.29 lb 9-32V 60 5.0A
XIL-PX18MW Mix 11.10″ 18 9,504 lm 6,660 lm 6.61 lb 9-32V 90 7.5A
XIL-PX36MW Mix 20.60″ 36 19,008 lm 13,320 lm 10.58 lb 9-32V 180 15.0A
XIL-PX54MW Mix 30.20″ 54 28,512 lm 19,980 lm 14.55 lb 9-32V 270 22.5A
XIL-PX72MW Mix 39.80″ 72 38,016 lm 26,640 lm 18.51 lb 9-32V 360 30.0A
